2. Problem 1: Floating Point (floating)
In this problem, we will investigate how floating-point numbers are represented in memory. Recall that
a float is a 32-bit value with a single sign bit, eight exponent bits, and 23 mantissa bits. Specifically, a
floating point number x with sign bit ‘sign’, exponent e , and mantissa bits m0, m1, . . . , m22 can be
written1
x = ( 1)sign
(1.m22m21m20 ...m0) 2e bias
where the mantissa is, of course, in base two. You will be given a list of N floating point values x1,
x2, . . . , xN . For each xi , your program should write its binary representation to the output file as
indicated below.
Suggested approach: You’ll need to use bitwise operations, but you cannot do so on a floating-point
number directly. Instead, you will need a way of considering a variable as either a float or an unsigned
int. We will use a union, which is valid in this case because we assume the size of the two data types is
the same.
union float bits {
float f;
unsigned int bits;
};
II print hex( 5.Of ) outputs "The float looks like Ox4OaOOOOO in hex." void
print hex( float f) {
union float bits t;
t.f = f;
printf( "The float looks like Ox%x in hex.n", t.bits );
}

3. Output Format
Lines 1...N : Line i contains a representation of the floating-point number xi ,
formatted as shown in the sample output.
Sample Output (file floating.out)
1.1OOOOOOOOOOOOOOOOOOOOOO * 2�O
1.O1OOOOOOOOOOOOOOOOOOOOO * 2�-3
-1.11O1O1O1O1OO1111111OOOO * 2�2
Input Format
Line 1: One integer N
Lines 2...N + 1: Line i + 1 contains floating point number xi
Sample Input (file floating.in)
3
1.5
O.15625
-7.333
Except for the case where x is a denormal floating point number, as discussed in
class, in which case the (unbiased) exponent is -126 and mantissa is written 0.m22m21
m20 ...m0.

4. /*
PROG: floating
LANG: C
*/
#include <stdio.h>
#include <stdlib.h>
#include <stdint.h>
#include <math.h>
#define ABSOLUTE_WIDTH 31
#define MANTISSA_WIDTH 23
#define EXPONENT_WIDTH 8
#define EXPONENT_MASK 0xffu
#define MANTISSA_MASK 0x007fffffu
#define EXPONENT_BIAS 127
union float_bits {
float f;
uint32_t bits;
};
void print_float( FILE *output, float f ) {
union float_bits t; t.f = f;
uint32_t sign_bit = ( t.bits >> ABSOLUTE_WIDTH );

5. if( exponent != 0 || mantissa != 0 ) {
fprintf( output, " * 2^%dn", (int) ( exponent - EXPONENT_BIAS ) );
uint32_t exponent = ( t.bits >> MANTISSA_WIDTH ) & EXPONENT_MASK;
uint32_t mantissa = ( t.bits & MANTISSA_MASK );
if( sign_bit != 0 ) {
fprintf( output, "-" );
}
if( exponent > 2 * EXPONENT_BIAS ) {
fprintf( output, "Infn" ); /* Infinity */
return;
} else if( exponent == 0 ) {
fprintf( output, "0." ); /* Zero or Denormal */
exponent = ( mantissa != 0 ) ? exponent + 1 : exponent;
} else {
fprintf( output, "1." ); /* Usual */
}
for( int k = MANTISSA_WIDTH - 1; k >= 0; --k ) {
fprintf( output, "%d", ( mantissa >> k ) & 1 );
}
}
}

6. int main() {
FILE *input = fopen( "floating.in", "r" ),
*output = fopen( "floating.out", "w" );
size_t N; float f;
fscanf( input, "%zu", &N );
for( size_t i = 0; i < N; ++i ) {
fscanf( input, "%f", &f );
print_float( output, f );
}
fclose( input );
fclose( output );
return 0;
}
Below is the output using the test data:
floating: 1: OK [0.004 seconds] OK!
2: OK [0.004 seconds] OK!
3: OK [0.004 seconds] OK!
4: OK [0.004 seconds] OK!
5: OK [0.005 seconds] OK!
6: OK [0.004 seconds] OK!
7: OK [0.004 seconds] OK!
