The Service Bus is part of Windows Azure and is designed to provide connectivity, queuing, and routing capabilities not only for the cloud applications but also for on-premises applications. Microsoft BizTalk Server enables organizations to connect and extend heterogeneous systems across the enterprise and with trading partners. Using both together enables a significant number of scenarios in which you can build secure, reliable and scalable hybrid solutions that span the cloud and on premises environments. Windows Azure BizTalk Services is a simple, powerful, and extensible cloud-based integration service that provides Business-to-Business (B2B) and Enterprise Application Integration (EAI) capabilities for delivering cloud and hybrid integration solutions. Windows Azure Mobile Services accelerates connected client application development by streamlining common backend tasks like structuring storage, authenticating users, and sending push notifications. In this session you will see how to integrate these technologies to build secure, reliable and scalable hybrid solutions that span the cloud and on premises environments.

4. Enterprises want to manage internal mobile
apps and consumer facing event- or productspecific mobile apps from the same portal as
core LOB apps
Small Businesses require solutions that
accelerate development time and decrease
development costs.
Developers shouldn’t have to constantly
reinvent the wheel and reproduce common
backend functionality
Consumers expect a continuous experience
across all devices

7. Windows Store iOS
Android
Windows Phone 8
iOS
Android
HTML 5/JS
SDKs
ServerSide
Scripts
Custom
API
Scheduler

8. Operation
Login
Query records
Insert record
Update record
Delete record
Description
Gets the user ID for a supplied authentication token.
Queries data in a table.
Inserts a new record into a table.
Updates an existing record in a table.
Deletes an existing record from a table.

10. 1. The HTML5/JS or Windows Store app sends a request to a custom API
2.
3.
4.
5.
6.
7.
8.
9.
using the InvokeApi method of the MobileServiceClient class.
The custom API sends a request to ACS to acquire a security token.
ACS issues and returns a security token.
The mobile service performs the following actions:
• Creates a SOAP envelope to invoke the WCF service. The Header contains
a RelayAccessToken returned by ACS.
• Uses the https module to send the SOAP request to the Relay Service.
The Relay Service forwards the request to WCF service.
The WCF service exposes a BasicHttpRelayBinding endpoint on the
Service Bus. It reads/writes/updates/deletes data from a local db.
The WCF service returns a response to the Relay Service.
The Relay Service forwards the message to the mobile service.
The custom API uses the xml2js Node.js module to change the format of the
response SOAP message from XML to JSON. The mobile service returns
data in JSON format to the client app.

11. var
var
var
var
namespace = 'your-servicebus-namespace';
issuerName = 'owner';
issuerSecret = 'XXXXXXXXXXXXXXXXXXX=';
https = require('https');
function getAcsToken(response, callback) {
var options = { host: namespace + '-sb.accesscontrol.windows.net', path: '/WRAPv0.9/', method: 'POST' };
var values = { wrap_name: issuerName, wrap_password: issuerSecret, wrap_scope: 'http://' + namespace + '.servicebus.windows.net/' };
var req = https.request(options, function (res) {
res.on('data', function (data) {
var token = qs.parse(data.toString('utf8'));
if (res.statusCode == 200) {
if (token.hasOwnProperty('wrap_access_token')) {
callback(token.wrap_access_token);
}
else {
response.send(400, "[getAcsToken]: ACS didn't return a valid token");
}
}
else {
response.send(res.statusCode, util.format('[getAcsToken]: %s', data));
}
});
});
req.write(qs.stringify(values));
req.end();
req.on('error', function (e) {
response.send(400, util.format('[getAcsToken]: %j', e));
});
}

12. function addProduct(token, request, response) {
if (request.body.hasOwnProperty('name') && request.body.hasOwnProperty('category') && request.body.hasOwnProperty('price')) {
var product = '<product xmlns:i="http://www.w3.org/2001/XMLSchema-instance">' +
'<productId>0</productId>' +
'<name>' + request.body.name + '</name>' +
'<category>' + request.body.category + '</category>' +
'<price>' + request.body.price + '</price>' +
'</product>'
var base64token = new Buffer(token).toString('base64');
var tokenId = uuid.v1();
var body = '<s:Envelope xmlns:s="http://schemas.xmlsoap.org/soap/envelope/">' +
'<s:Header>' +
'<RelayAccessToken xmlns="http://schemas.microsoft.com/netservices/2009/05/servicebus/connect">' +
'<wsse:BinarySecurityToken wsu:Id="uuid:' + tokenId + '" ' +
'ValueType="http://schemas.xmlsoap.org/ws/2009/11/swt-token-profile-1.0" ' +
'EncodingType="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-soap-message-security-1.0#Base64Binary" ' +
'xmlns:wsse="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-wssecurity-secext-1.0.xsd" ' +
'xmlns:wsu="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-wssecurity-utility-1.0.xsd">' +
base64token +
'</wsse:BinarySecurityToken>' +
'</RelayAccessToken>' +
'</s:Header>' +
'<s:Body>' +
'<AddProduct xmlns="http://windowsazure.cat.microsoft.com/samples/servicebus">' +
product +
'</AddProduct>' +
'</s:Body>' +
'</s:Envelope>';
var headers = { SOAPAction: 'addProduct', 'Content-Type': 'text/xml' };
var options = { host: namespace + '.servicebus.windows.net', path: '/products/basichttp', headers: headers, method: ‘POST'};

13. var req = https.request(options, function (res) {res.on('data', function (data) {
var soap = data.toString('utf8');
if (res.statusCode == 200 || res.statusCode == 201 || res.statusCode == 202) {
var xml2js = require('xml2js');
var parser = new xml2js.Parser();
parser.parseString(soap, function (error, json) {
if (error) {
response.send(400, '[addProduct]: An error occurred while parsing the response.');
}
else {
try {
var product = json["s:Envelope"]["s:Body"]["AddProductResponse"]["product"];
response.send(200, product);
}
catch (ex) {
response.send(400, '[addProduct]: An error occurred while processing the response.');
}
}
});
}
else {
response.send(400, '[addProduct]: An error occurred while invoking the downstream service.');
}
});
});
req.write(body);
req.end();
}

14. 1. The HTML5/JS site or Windows Store app sends a request to a
2.
3.
4.
5.
6.
7.
8.
custom API using the InvokeApi method
The custom API sends a request to ACS to acquire a security token.
ACS issues and returns a security token.
The mobile service uses the https module to send a request to the
Relay Service and specifies the wrap access token issues by ACS in
the Authorization HTTP header
The Relay Service forwards the request to the WCF service.
The WCF service exposes a REST WebHttpRelayBinding endpoint on
the Service Bus. It reads/writes/updates/deletes data from a local db.
The WCF service returns a response to the Relay Service.
The Relay Service forwards the message to the mobile service. The
mobile service returns data in JSON format to the client app.

15. function addProduct(token, request, response) {
if (request.body.hasOwnProperty('name') && request.body.hasOwnProperty('category') && request.body.hasOwnProperty('price')) {
var product = { productId: 0, name: request.body.name, category: request.body.category, price: request.body.price };
var headers = { 'Authorization': token, 'Content-Type': 'application/json' };
var options = { host: namespace + '.servicebus.windows.net', path: '/products/webhttp/addproduct', headers: headers, method: 'POST' };
var req = https.request(options, function (res) {
res.on('data', function (data) {
var body = data.toString('utf8');
if (body) {
console.log('[addProduct]: response body: ', body);
}
if (res.statusCode == 200 ||res.statusCode == 201 || res.statusCode == 202) {
response.send(200, JSON.parse(body));
}
else {
response.send(400, '[addProduct]: An error occurred while invoking the downstream service.');
}
});
});
req.write(JSON.stringify(product));
req.end();
req.on('error', function (e) { response.send(400, util.format('[addProduct]: %j', e)); });
}
else {
var message = "[addProduct]: The request body is not in JSON format or doesn't contain a well-formed product.in ";
response.send(400, message);
}
}

16. •
•
•
•
•
•
•
•
•
•
The HTML5/JS site or Windows Store app sends a JSON request to a custom API.
The custom API sends a request to ACS to acquire a security token.
ACS issues and returns a security token.
The mobile service performs the following actions:
• Extracts the wrap access token from the security token issued by ACS and assigns its
value the Authorization HTTP request header.
• Creates a SOAP envelope to invoke the XML Request-Reply Bridge.
• Uses the https module to send the SOAP envelope to the bridge.
The bridge performs the following actions:
outes the request to EUROPE or US service based on the value of the location prop.
The Relay Service forwards the message to the target service.
The service returns a response to the bridge via the Relay Service .
The bridge transforms and returns the response to the mobile service.
The custom API uses the xml2js Node.js module to change the format of the response
SOAP message from XML to JSON.
The mobile service returns data in JSON format to the client application.

17. var bridgePath = '/default/CalculatorService';
var bizTalkServiceScope = 'http://<your-biztalk-service-namespace>.biztalk.windows.net' + bridgePath;
var https = require('https');
var qs = require('querystring');
function getAcsToken(response, callback) {
var options = { host: ‘<your-service-bus-namespace>.accesscontrol.windows.net', path: '/WRAPv0.9/', method: 'POST' };
var values = { wrap_name: 'owner', wrap_password: 'XXXXXXXXXXXXXXXXXXXXXXXXXX=', wrap_scope: bizTalkServiceScope };
var req = https.request(options, function (res) {
res.on('data', function (data) {
var body = qs.parse(data.toString('utf8'));
if (res.statusCode == 200) {
if (body.hasOwnProperty('wrap_access_token')) {
var header = 'WRAP access_token="' + body.wrap_access_token + '"';
callback(header);
}
else {
response.send(400, util.format("[getAcsToken]: ACS didn't return a valid token"));
}
}
else {
response.send(res.statusCode, util.format('[getAcsToken]: %s', data));
}
});
});
req.write(qs.stringify(values));
req.end();
req.on('error', function (e) { response.send(400, util.format('[getAcsToken]: %j', e)); });
}

18. function callCalculatorBridge(token, request, response) {
if (request.body.hasOwnProperty('location') && request.body.hasOwnProperty('operations') && Array.isArray(request.body.operations)) {
var operations = request.body.operations;
var body = '<?xml version="1.0" encoding="utf-8"?>' +
'<s:Envelope xmlns:a="http://www.w3.org/2005/08/addressing" ' +
...
'<operations>';
var items = new Array(operations.length);
var index = 0;
for (var i = 0; i < operations.length; i++) {
if (operations[i].hasOwnProperty('op') && operations[i].hasOwnProperty('op1') && operations[i].hasOwnProperty('op2')) {
body = body + '<operation>' + '<op>' + operations[i].op + '</op>' + '<op1>' + operations[i].op1 + '</op1>' +
'<op2>' + operations[i].op2 + '</op2>' + '</operation>';
items[index] = operations[i];
index++;
}
}
body = body + '</operations></request></s:Body></s:Envelope>';
var headers = {'Accept':'application/soap+xml','Content-Type':'application/soap+xml', 'Authorization': token};
var options = {host: 'babonet.biztalk.windows.net', path: '/default/calculatorservice',headers: headers, method: 'POST', agent: agent };
var req = https.request(options, function (res) {
...
});
});
req.write(body, 'utf8');
req.end();
req.on('error', function (e) { response.send(400, util.format('[callCalculatorBridge]: %j', e)); });
}
else {
response.send(400, "[callCalculatorBridge]: The request body is not in JSON format or doesn't contain all the necessary fields.");
}
}

19. •
•
•
•
•
•
•
•
•
•
The HTML5/JS site or Windows Store app or Windows Phone 8 sends
a JSON request to a custom API.
The custom API sends a request to ACS to acquire a security token.
ACS issues and returns a security token.
The mobile service performs the following actions:
• Extracts the wrap access token from the security token issued by
ACS and assigns its value the Authorization HTTP request header.
• Creates a SOAP envelope to invoke the XML Request-Reply Bridge.
• Uses the https module to send the SOAP envelope to the bridge.
The bridge performs the following actions:
outes the request to the BizTalk Adapter Service via SB Relay.
The BizTalk Adapter Service accesses data using the SQL Adapter.
The BizTalk Adapter Service returns a response to the bridge via SB
Relay.
The bridge transforms and returns the response to the mobile service.
The custom API uses the xml2js Node.js module to change the format of
the response SOAP message from XML to JSON.
The mobile service returns data in JSON format to the client application.

20. •
The HTML5/JS site or Windows Store app or Windows Phone 8 sends a
JSON request to an ASP.NET Web API REST service.
The custom API sends a request to ACS to acquire a security token.
ACS issues and returns a security token.
The Web API service performs the following actions:
• Extracts the wrap access token from the security token issued by ACS
and assigns its value the Authorization HTTP request header.
• Creates a SOAP envelope to invoke the XML Request-Reply Bridge.
• Sends the message to the BizTalk Service using POST method.
The bridge performs the following actions:
•
•
•
•
outes the request to the BizTalk Adapter Service via SB Relay.
The BizTalk Adapter Service accesses data using the SQL Adapter.
The BizTalk Adapter Service returns a response to the bridge via SB Relay.
The bridge transforms and returns the response to the Web API service.
The Web API service returns data in JSON format to the client application.
•
•
•
•

21. 1.
2.
3.
4.
5.
6.
7.
8.
9.
The client app sends auth credentials to the MS.
The authentication provider validates the credentials
(username and password) and issues a security token.
The mobile service returns its access token to the client
application. The user sends a new item to the MS.
The insert script for the TodoItem table handles the
incoming call. The script calls the authentication
provider using the request module to retrieve the user
name from the user token.
The script sends a request to ACS to acquire a security
token. The script calls BizTalk Server via a Relay
Service to retrieve the user address.
The script inserts the new item in the TodoItem table.
The script reads the Channel URI of Windows Phone 8
and Windows Store apps from the Channel table.
The script sends Push Notifications.
The script uses the azure module to send a notification
to BizTalk Server via a Service Bus queue.

22. function sendMessageToServiceBus() {
var azure = require('azure');
var serviceBusService = azure.createServiceBusService('<your-service-bus-namespace-name>', '<your-service-bus-namespace-key>');
var queueOptions = { EnableBatchedOperations: true, RequiresDuplicateDetection: true, DuplicateDetectionHistoryTimeWindow: 'PT8H' };
serviceBusService.createQueueIfNotExists('mobileservices/todoitem', queueOptions, function (error) {
if (error) {
console.error("An error occurred creating/accessing the Service Bus queue: ", error);
}
else {
var builder = require('xmlbuilder');
var root = builder.create('todoItem', { 'version': '1.0', 'encoding': 'UTF-8' });
root.ele('userId', user.userId);
root.ele('text', item.text);
root.ele('complete', item.complete.toString());
var message = {
body: root.end({ 'pretty': true, 'indent': ' ', 'newline': 'n' }),
messageId: item.id,
customProperties: {
source: 'Mobile Services',
author: 'Paolo Salvatori'
}
};
// Send the message to the queue
serviceBusService.sendQueueMessage('mobileservices/todoitem', message, function (error) {
if (!error) { console.log('Sent message: ' + message); }
});
}
});
}

23. http://code.msdn.microsoft.com/windowsazure/How-to-integrate-a-Mobile-8780500c
http://code.msdn.microsoft.com/windowsazure/How-to-integrate-a-Mobile-1ee6a5ea
http://code.msdn.microsoft.com/windowsazure/How-to-integrate-Mobile-6718aaf2
http://code.msdn.microsoft.com/windowsazure/How-to-integrate-Mobiles-77b25d12
http://code.msdn.microsoft.com/windowsazure/How-to-integrate-Mobile-f2fca10d
http://code.msdn.microsoft.com/windowsazure/How-to-send-a-large-c36ab70e

24. http://www.windowsazure.com/en-us/develop/mobile/
http://www.windowsazure.com/en-us/develop/mobile/resources-html/
http://code.msdn.microsoft.com/Upload-File-to-Windows-c9169190
http://blogs.msdn.com/b/carlosfigueira/archive/2012/10/25/getting-user-information-on-azure-mobile-services.aspx
http://blogs.msdn.com/b/carlosfigueira/archive/2012/10/23/troubleshooting-authentication-issues-in-azure-mobileservices.aspx

25. http://www.windowsazure.com/en-us/develop/nodejs/how-to-guides/table-services/
http://www.windowsazure.com/en-us/develop/nodejs/how-to-guides/service-bus-queues/
http://www.windowsazure.com/en-us/develop/nodejs/how-to-guides/service-bus-topics/
http://www.windowsazure.com/en-us/develop/nodejs/how-to-guides/sendgrid-email-service/

26. http://blogs.msdn.com/b/paolos
http://www.thejoyofcode.com/
http://www.nickharris.net/
http://blogs.msdn.com/b/carlosfigueira/
